TENSILE TESTER - HORIZONTAL (TOUCH SCREEN)
UEC-1005 D II

The UEC Horizontal Tensile Tester enables to provide Rapid & Efficient determination of Tensile Strength, Stretch (Elongation) & Elongation Percentage, Tensile Energy Absorption (TEA), Breaking Length (BL) of Paper, Tissue Paper and Board in Wet or Dry State. It is equipped with an "Auto Sensing & Auto Clamping", High Friction Clamps which prevents Test Pieces from slippage during measurements.

The Equipment is controlled through Touch Screen Cum Graphical LCD, wherein the Parameters are set according to the Standards. When the unit switches to the Test Mode through Main Menu, the Test Procedure starts automatically, after Placing the Test Sample. The Test Values as well as the Graph are displayed on the Touch Screen Panel, after rupture of the Test Sample. The unit is provided with Standard Load Cell and the Clamps for the Test Width size 15 mm.

Extra on Demand:

“Sample Preparation Cutter (Sample Size 15 x 300 mm)”

“Load Cell of Capacity 20/50 Kg f.(200/500 N)”

“Standard Calibration Jig with Check Weights”

“Thermal Printer to Print the Instant Test Data”

“Special Dedicated Window Based Software to Interface the Main Unit with Computer & Printer”

Product Code UEC-1005 D II
Equipment Category Physical Property Testing Equipment
Weight


Dimension

79.0 x 50.0 x 29.5 cm.
Applicable Standards

SCAN P 38, SCAN P 67, TAPPI T494,TAPPI T541, CPPA D.34, ISO 1924/2, BS 4415, DIN 53112, APPITA/AS 1301.448, JIS P 8115, FINAT
Range Available


Testing Applications Newsprint (Breaking Length)
Writing Printing/copier Paper (Breaking Length)
Tissue & Soft Material (Breaking Length)
Accessories
