This equipment determines the bursting strength of corrugated fiber board & paperboard. The bursting pressure, at the time of rupture is recorded on the digital display panel as well as on the sensitive pressure gauge for cross checking the B.S. in Kg /Cm². The equipment is operated through a Key Pad mounted on the front panel, enabling to feed the GSM of paper. The results after rupture of the specimen is displayed for the average readings of bursting strength & burst factor simultaneously.
Measuring Range: 0 - 50 Kg./Cm².
Accessories on Demand:
“Rubber Membrane Diaphragms”
“Standard Reference Testing Foils”
“Glycerol Fluid”
| Product Code | UEC-1010 B2 |
| Equipment Category | Physical Property Testing Equipment |
| Weight |
50.500 Kg. |
| Dimension |
55.0 x 64.0 x 44.5 cm. |
| Applicable Standards |
SCAN P 24, P 25, TAPPI T403, T807, T810, CPPA D.8, ISO 2758, 2759, FEFCO No.4, BS 3137, JIS 8112, ASTM D 751, D 3393 |
| Range Available |
|
| Testing Applications |
Kraft Liner/fluting Paper/sack (Bursting Strength) |
| Accessories |
|
