GRAMMAGE TESTER DIGITAL (PAN MODEL)
GRAMMAGE TESTER DIGITAL (PAN MODEL)
UEC-1002 B

The digital pan model grammage tester is designed to measure the basis weight (GSM) of paper and other sheet materials by weighing a small test sample with specified dimensions. The equipment is portable, features a battery backup, and includes an auto-zero adjustment facility. It has a measuring range of 0 to 3000 GSM (maximum) for sample sizes of 10 cm x 10 cm and 20 cm x 25 cm, with an accuracy of 0.1 GSM. The sample should be placed in the measuring pan, and the GSM reading will be displayed directly on the LED screen.

Optional on demand:

  • Sample preparation templates are available in the sizes of 10 x 10 cm and 20 x 25 cm.
Product Code UEC-1002 B
Equipment Category Physical Property Testing Equipment
Weight

2.400 Kg

Dimension

18.0 x 24.0 x 8.0 cm.

Applicable Standards


Range Available


Testing Applications Newsprint (Grammage)
Writing Printing/copier Paper (Grammage)
Duplex And Art Paper (Grammage)
Kraft Liner/fluting Paper/sack (Grammage)
Corrugated Fibre Board Box Board (Grammage)
Tissue & Soft Material (Grammage)
